| 適用范圍 | 空調(diào)，冷水，冷藏 |
|---|---|
| 功率 | 16.30（kw） |
| 重量 | 147（kg） |
| 類型 | 空調(diào)用制冷設備 |
| 結構類型 | 半封閉式 |
| 排量類型 | 定排量壓縮機 |
| 品牌 | Bitzer/比澤爾 |
| 型號 | 4PES-15 |
| 加工定制 | 否 |
本公司經(jīng)營保鮮冷庫機組壓縮機-比澤爾壓縮機4，質量保證，歡迎咨詢洽談。
4PCS-15.2
| Technical Data | |
| Displacement (1450 RPM 50Hz) | 48,50 m3/h |
| Displacement (1750 RPM 60Hz) | 58,53 m3/h |
| No. of cylinder x bore x stroke | 4 x 65 mm x 42 mm |
| Motor voltage (more on request) | 380..420V YY/3/50Hz |
| Max operating current | 31.0A |
| Winding ratio | 50/50 |
| Starting current (Rotor locked) | 81.0A Y/ 132.0A YY |
| Weight | 142 kg |
| Max. pressure (LP/HP) | 19 / 28 bar |
| Connection suction line | 42 mm - 1 5/8'' |
| Connection discharge line | 28 mm - 1 1/8'' |
| Connection cooling water | -- |
| Oil type R134a/R407C/R404A/R507A | tc<55°C: BSE32 / tc>55°C: BSE55 (Option) |
| Oil type R410A | -- |
| Oil type R22 (R12/R502) | B5.2 (Standard) |
| Oil type R744 (CO2) | -- |
| Oil charge | 2,60 dm³ |
| Crankcase heater | 0..140 W PTC (Option) |
| Oil pressure monitoring | -- |
| Oil level monitoring | OLC-K1 (Option) |
| Oil service valve | Option |
| Discharge gas temperature sensor | Option |
| Motor protection | SE-B1 |
| Enclosure class | IP65 |
| Start unloading | Option |
| Capacity control | 100-50% (Option) |
| Additional fan | Option |
| Water-cooled cylinder heads | -- |
| CIC System | -- |
| Vibration dampers | Standard |
| Sound power level (+5°C / 50°C) | 75,5 dB(A) @ 50Hz |
| Sound power level (-10°C / 45°C) | 76,5 dB(A) @ 50Hz |
| Sound power level (-35°C / 40°C) | (81,0) dB(A) @ 50Hz |
| Sound pressure level @ 1m (+5°C / 50°C) | 67,5 dB(A) @ 50Hz |
| Sound pressure level @ 1m (-10°C / 45°C) | 68,5 dB(A) @ 50Hz |
